Classeq | SKU:
D400DUO - 1p13am
Classeq Dishwashers D400DUO 450x760x517mm
£4,203.00
Unit price
/
Unavailable
£3,502.50 ex. VAT
Classeq Dishwashers D400DUO 450x760x517mm - D400DUO / 1 Phase 13 amp is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Classeq Dishwashers D400DUO 450x760x517mm
From
£4,203.00
Unit price
/
Unavailable
Description
Description
D400DUO - Technical Data at a Glance
A DUO Dishwasher with a 400mm x 400mm basket size. Wash up to 270 plates an hour.
Dimensions
Width: 450 mm
Height: 760 mm
Depth: 517 mm
Door Depth - Open: 865 mm
Basket Size: 400 x 400 mm
Rack Size: 400 x 400 mm
Clear entry height: 311 mm
Performance
Theoretical max racks per hour: 30
Plates per rack : 9
Number of wash programmes: 3
Duration of wash programmes: 2, 3 & 5 min
Plates per hour: 270
Wash tank element: 2 kW
Rinse tank element: 2.6 kW
Wash tank capacity: 9.77 Litres
Rinse tank capacity: 6.5 Litres
Rinse water consumption at 3 bar: 3 Litres
Wash tank temperature: 55 °C
Rinse tank temperature: 82 °C
Wash pump power: 0.25 kW
Rinse pump power: 0.1 kW
Rinse booster pump: included
Water softener: optional
Hydraulic Specifications
Water supply connection: G3/4" (3/4"Bsp)
Minimum allowed supply water pressure: 0.5 bar (DUO) / 2-4 bar (DUOWS)
Required water flow rate: 11L/min (DUO) & 4L/min (DUOWS)
Minimum incoming water temperature: 4 °C
Maximum incoming water temperature: 55°C
Gravity drain height (from machine base): 40mm
Pumped drain height (from machine base): 540mm
Drain Size: o40mm
Electrical Specifications
Standard Configuration
Amps Required: 13A (1 phase)
Standard Operating voltage: 220-240V / 1N~ / 50Hz
Total connected load: 2.85kW
Optional Configuration
Amps Required: 13A (3 phase)
Standard Operating Voltage: 380-415V / 3N-/50Hz
Total Connected Load: 6.58kW
Optional Configuration
Amps Required: 30A (1 phase)
Standard Operating Voltage: 220-240V / 1N~ / 50Hz
Total Connected Load: 6.58kW
Additional Info
Noise level: < 70 dB
Empty Weight: 40.3kgs
Packed weight: 49.8kgs (DUO) / 51.9kgs (DUOWS)
Fully loaded weight: 46.8kgs
Service: Installation
